This chart is provided to help you identify the small parts used in assembly. Important: Some parts may
have been pre-assembled for shipping purposes; if you cannot find a part in the parts bags, check to
see if it has been pre-assembled.
REMOVE THIS PART IDENTIFICATION
CHART FROM THE MANUAL!
Please Note: The assembly is divided into four stages: 1) frame assembly, 2) press and butterfly
arm assembly, 3) cable and pulley assembly, and 4) seat and backrest assembly. The hardware
for each stage is packaged separately. Wait until you begin each assembly stage to open that
parts bag.
WESY85200 R0896A
