Weider 8970 - Cable Diagrams; Butterfly Cable Routing; High Cable Routing; Short Cable Routing

High Cable (45)
Length: 2.6m
CABLE DIAGRAMS
The cable diagrams below show the proper routing of the Butterfly Cable (46), the High Cable (45), the Low
Cable (47), and the Short Cable (83). Use the diagrams to make sure that the cables and the cable traps have
been assembled correctly. If the cables have not been correctly routed, the weight system will not function prop-
erly and damage may occur. The numbers show the correct route for each cable.
Make sure that the cable
t
raps do not touch or bind the cables.
4
2
5
4
1
2
5
1
1
2
3
4
5
6
7
8
Butterfly Cable (46)
Length: 1.3m
Low Cable (47)
Length: 4.5m
Short Cable (83)
Length: 1.0m
3
3
2
1
3
17
