Weider 900 - CABLE DIAGRAM

18
The cable diagram below shows the proper routing of the Short Cable (47), the Low Cable (48), the Press
Cable (49), and the High Cable (50). Use the diagrams to make sure that the cables have been assembled cor-
rectly. If the cables have not been correctly routed, the weight system will not function properly and damage may
occur. The numbers show the correct route for each cable.
