M6 Washer (90)
M8 Nylon Locknut (101)
M10 Washer (108)
M10 Nylon Locknut (84)
M6 Nylon Locknut (103)
M4 x 16mm
Self-tapping
Screw (100)
M8 x 25mm
Shoulder Bolt (92)
2 1/4" Bolt Set (86)
M10 x 40mm Bolt (104)
M10 x 35mm Screw (89)
M10 x 50mm Bolt (105)
M10 x 45mm Bolt (95)
M
PART IDENTIFICATION CHART
R
efer to the drawings below and on page 6 to identify small parts used in assembly. The number in parentheses
by each drawing is the key number of the part, from the PART LIST on page 32.
Note: Some small parts may
have been preattached. If a part is not in the parts bag, check to see if it has been preattached.
5
