Weider PRO 345 - Attach Backrest; Attach Seat

10
11
30
2
13
13. Attach the Seat (11) to the Seat Frame (2)
with four M6 x 40mm Screws (30) and four M6
Washers (26); start all the Screws, and then
tighten them.
26
26
16
16
48
5
6
12
12. Attach an M10 x 20mm Bolt (47) and an M10
Locknut (33) to the hole in the end of the Pivot
Bracket (7).
Then, attach the Backrest (6) to the Backrest
Frame (5) with two M8 x 45mm Screws (48) and
two M8 Washers (16).
48
7
47
33
