24
113
26
ADJUSTING THE BACKREST
To adjust the position of the Press Backrest (113),
disengaging the Knob (43) from the Left Upright (26)
and move the Backrest to the desired position.
Reengage the Knob into the Left Upright and the
Backrest Frame (53). Make sure the Knob is fully
t
ightened.
53
43
LOCKING THE WEIGHT STACK
Lock the weight stack by inserting the Lock Pin (65)
through a Weight Guide (44) and securing the Lock
(48) onto the Lock Pin.
44
48
65
