Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover
of the user’s manual for information about ordering replacement parts.
If a part is missing, call
toll-free
1-877-992-5999.
Key No. Qty. Description Key No. Qty. Description
1
1 Right Base
2 1 Right Upright
3 1 Right Seat Frame
4 1 Leg Lever
5 1 Right Top Frame
6 1 Left Butterfly Arm
7 1 Right Butterfly Arm
8 1 Seat
9 1 Butterfly Backrest
10 1 Shroud
11 2 Shroud Cover
12 1 Seat with Tag
13 1 Lat Bar
14 1 Butterfly Frame
15 2 Large Foam Pad
16 1 Long Pad Tube
17
4 Foam Cap
18 4 Small Foam Pad
19 6 63mm Round Inner Cap
20 8 50mm Round Inner Cap
21 1 Lock Plate
22 1 M10 x 103mm Bolt
23 4 Arm Bushing
24 1 Leg Pin
25 1 Left Base
26 1 Left Upright
27 1 Left Seat Frame
28 1 Leg Press Frame
29 1 Press Frame
30 2 Press Arm
31 2 Support Plate
32 2 Press Handle
33 2 M12 Washer
34 2 Press Arm Cap
35 1 Short Pad Tube
36 1
Left Top Frame
37 1 M8 x 86mm Shoulder Bolt
38 1 Foot Plate
39 2 M8 x 20mm Shoulder Bolt
40 1 50mm Round Outer Cap
41 1 M8 x 67mm Shoulder Bolt
42
1
56mm Round Inner Cap
43 1 Knob
44 2 Weight Guide
45 2 Weight Bumper
46 1 Weight Tube Bumper
47
1
Weight Tube
48 1 Lock
49 1 M12 Nut
50 2 “U”-bracket
51 2 Pulley Plate
52
1
Center Base
53 1 Backrest Frame
54 1 25mm x 40mm Inner Cap
55 8 Weight
56 1 Top Weight
57 1
Weight Pin
58 2 Handgrip
59 1 Leg Bumper
6
0 1 M10 x 72mm Bolt
61 1 Double “U”-bracket
62 4 “V”-pulley
63 23 90mm Pulley
64 9 M10 x 48mm Bolt
65 1 Lock Pin
66 34 Half Finger Guard
67 2 Base Bushing
68 13 Cable Trap
69 8 M8 x 72mm Carriage Bolt
70 1 M10 x 134mm Bolt
71 1 M10 x 115mm Bolt
72 4 M10 x 106mm Bolt
73 2 M10 x 62mm Bolt
74 2 M10 x 85mm Bolt
75 2 M10 x 80mm Bolt
76
1 M10 x 75mm Bolt
77 4 M10 x 65mm Bolt
78 1 M6 x 35mm Screw
79 1 Ab Strap
80 4 M10 x 43mm Bolt
81 2 M10 x 45mm Button Bolt
82 23 M8 x 77mm Bolt
83 1 M8 x 95mm Bolt
84 2 M10 x 46mm Bolt
85 2 M8 x 70mm Bolt
86 4 M8 x 66mm Bolt
87 4 M6 x 22mm Bolt
88 14 M6 x 16mm Screw
89 2 M4 x 16mm Self-tapping Screw
90 34 M10 Nylon Locknut
91 42 M8 Nylon Locknut
92 4 M6 Nylon Locknut
93 1 Handle
94 1 Chain
95 3
Cable Clip
96 1 M4 Washer
97 5 M6 Washer
98 29 M8 Washer
99 22 M10 Washer
100 4 M10 Large Washer
101
6
M10 x 12mm Spacer
102 4 M10 x 19mm Spacer
103 1 M8 x 13mm Spacer
104 4 Full Finger Guard
105 2 Quarter Finger Guard
106
1
Butterfly Cable
107 1 Ab Cable
108 1 Short Cable
109 1 Press Cable
110 1 Weight Cable
1
1
1 3 Large Cable Trap
112 2 20mm x 40mm Inner Cap
113 1 Press Backrest
# 1 User’s Manual
# 1 Exercise Guide
#
2
Grease Packet
# 1 Allen Wrench
PART LIST—Model No. 831.15402.2 R0905A
