30
LOCKING THE LEG LEVER
T
o lock or unlock the Leg Lever (12), remove the
Lock Plate Pin (95) from the Lock Plate (14). Move
t
he Lock Plate to either the position shown on the
Front Leg (10), or the indicated hole in the Leg Lever.
Insert the Lock Pin back through the Lock Plate.
12
H
ole
95
14
1
0
