Weider Pro 9450 - Part List; Comprehensive Component List

PART LIST—Model No. WEEVSY39120 R1202A
Key No. Qty. Description
1 10 5/16” x 2 1/2” Carriage Bolt
2 6 1/4” Nylon Locknut
3 31 5/16” Nylon Locknut
4 1 Base
5 1 Stabiliser
6 1 1” Square Inner Cap
7 1 5/8” x 9/16” Spacer
8 10 5/16” Washer
9 12 3/8” Washer
10 11 1/4” Washer
11 9 5/16” x 2 3/4” Bolt
12 9 3/8” x 2” Bolt
13 2 Seat
14 1 5/16” x 2 3/4” Carriage Bolt
15
16 3 1/2” Pulley
16 1 3/8” x 3 1/2” Bolt
17 1 Press Frame
18 6 1/4” x 3/4” Screw
19 4 Weight Bumper
20 1 Pulley Bracket
21 17 3/8” Nylon Locknut
22 4 5/16” x 2 1/2” Bolt
23 1 Low Cable
24 2 5/16” x 1 3/4” Bolt
25 16 Weight
26 2 Weight Pin
27 8 2” Square Inner Cap
28 2 Pad Tube
29 1 Leg Lever
30 4 Foam Pad
31 3 Long Cable Trap
32 4 1 1/2” Square Inner Cap
33
3
5/16” x 2 1/4” Bolt
34 4 3/4” Round Inner Cap
35
1
3/8” x 2” Eyebolt
36
1
Front Seat Frame
37 2 Seat Plate
38
1
1/4” x 2” Carriage Bolt
39
1
Nylon Strap
40 1 Seat Knob
41
1
Front Backrest
42
1
Front Upright
43 4 1/4” x 2 1/2” Screw
44
6
1 3/4” Square Inner Cap
45
2
10” Pad
46 2 Press Arm
47
1
Left
Arm
48
1
Right
Arm
49 4 1” Round Inner Cap
50
3
“V”-Pulley
51
2
2” Square Outer Cap
52 1 Chain
53
3
Cable Clip
54
1
Lat Bar
55 1 Top Frame
56 1 Leg Press Upright
57 2 Long “U”-Bracket
58 1 High Cable
59 1 3/8” x 8” Bolt
60 2 5/16” x 6” Bolt
61 4 1/2” x 3/4” Spacer
62 2 Long Weight Guide
63 2 Weight Tube
64 2 Weight Tube Bumper
65 2 Top Weight
66 3 Cable Trap
67 2 3/8” x 3 1/4” Bolt
68 1 5/16” x 5” Bolt
69 4 1” Retainer
70 2 1” Round Cover Cap
71
2 Small “U”-Bracket
72 1 Military Press Cable
73 2 Short Weight Guide
74 1 Rear Upright
75 2 Round Inner Cap
76 1 3 1/2” Low Pulley
77 20 Pulley Cover
78 1 Leg Press Cable
79 1 Leg Press Seat Frame
80 1 Pivot Arm
81 1 1/4” x 2” Machine Screw
82 1 Handle
83 8 5” Plastic Grip
84 1 Military Press Arm
85 1 Leg Press Backrest
86 3 3/8” x 2 1/2” Bolt
87 1 #8 x 1/2” Self-tapping Screw
88 6 3/8” x 3 3/4” Bolt
89
2
1 1/8” x 2 1/2” Plastic Bushing
90 2 1” x 7/8” Plastic Bushing
91
1
Rubber Bumper
92
1
1/4” x 2 1/2” Carriage Bolt
93 2 5/16” Nylon Jam Nut
94
1
Press Bracket
95
1
Leg Press Plate
96 1 Leg Press Arm
97
1
Press Pin
98
2
Bushing
99 6 3/8” Nylon Jam Nut
100
1
3/8” x 3” Bolt
101
1
3/8” x 5 1/4” Bolt
102 2 Grip Pad
103
1
Ab Strap
104
2
Locking Pin
105 2 Lock
*
1
User’s Manual
*
1
Exercise Guide
*These parts are not shown on the EXPLODED
DRA
WING.
