5/16" Nylon Locknut (3)
1/4" Washer (10)
5/16" Washer (8)
1" Retainer (69)
3/8" Washer (9)
1/4" x 2 1/2" Screw (43)
3/8" Nylon Lock Nut (21)
1/4" x 2" Machine Screw (81)
5/16" Nylon Jam Nut (93)
5/16" x 2 1/2" Carriage Bolt (1)
5/16" x 2 3/4" Carriage Bolt (14)
3/8" x 2" Bolt (12)
3/8" x 3 1/2" Bolt (16)
5/16" x 2 1/2" Bolt (22)
3/8" x 2 1/2" Bolt (86)
1/4" x 2" Carriage Bolt (38)
5/16" x 5" Bolt (68)
3/8" x 3 3/4" Bolt (88)
3/8" x 8" Bolt (59)
Cable Clip (53)
1" x 7/8" Plastic Bushing (90)
5/16" x 6" Bolt (60)
5/16" x 2 3/4" Bolt (11)
5/16" x 2 1/4" Bolt (33)
3/8" x 5 1/4" Bolt (101)
3/8" x 3" Bolt (100)
3/8" x 3 1/4" Bolt (67)
1/4" Nylon Locknut (2)
1/4" x 2 1/2" Carriage Bolt (92)
5/16" x 1 3/4" Bolt (24)
#8 x 1/2" Self-
tapping Screw (87)
3/8" Nylon Jam Nut (99)
3 1/2" Pulley (15)
(Not shown to scale)
"V"-Pulley (50)
(Not shown to scale)
1/4" x 3/4" Screw (18)
1 1/8" x 2 1/2" Plastic Bushing (89)
PART IDENTIFICATION CHART—Model No. WEEVSY39120 R1202A
