10mm Spacer (20)
M10 x 65mm Bolt (23)
M8 Nylon Locknut (9)
M8 x 58mm Bolt (16)
M6 Washer (30)
M10 x 180mm Bolt (22)
M8 Flat Washer (13)
M10 Washer (6)
M10 x 22mm Bolt (7)
M6 x 16mm Screw (3)
M10 Nylon Locknut (11)
M6 x 64mm Screw (4)
M10 x 45mm Bolt (38)
M10 x 68mm Bolt (39)
M10 x 58mm Carriage Bolt (8)
Refer to the drawings below to identify small parts used in assembly. The number in parentheses below each
drawing is the key number of the part, from the P
ART LIST on page 14.
Note: Some small parts may have
been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
PART IDENTIFICATION CHART
To Next Page
