Part Identification Chart—Model No. WEBE19301
R1200A
M10 Large
Washer (58)—6
M10 Small
Washer (6)—14
M8 Nylon
Locknut (54)—1
M10 Nylon
Locknut (11)—40
M10 x 75mm Bolt (39)—2
M10 x 30mm Bolt (38)—2
M10 x 45mm Bolt (40)—3
M10 x 80mm Bolt (41)—24
M10 x 25mm Bolt (43)—4
M8 x 70mm Bolt (30)—1
M10 x 65mm Bolt (56)—7
M10 x 20mm Bolt (26)—2
M8 x 20mm Screw (50)—2
Refer to the drawings below to identify small parts used in assembly. The number in parentheses below each
drawing is the key number of the part, from the Part List in the center of this manual. The number following the
key number is the quantity needed for assembly. Note: Some small parts may have been pre-attached. If a
part is not in the parts bag, check to see if it has been pre-attached.
