8
5
5. Attach the Right Rear Upright (5) to the Right
Front Upright (3) with two M10 x 20mm Screws
(22), two M10 Split Washers (23), and two M10
Washers (20); do not fully tighten the Screws
yet.
Repeat this step on the other side of the
weight rack.
6. Identify the Pull-up Bar (8) and orient it so that
the long side of the bracket (B) is in the indi-
cated location.
Attach the Pull-up Bar (8) to the Right Front
Upright (3) with two M10 x 95mm Bolts (19), an
M10 Split Washer (23), an M10 Washer (20),
and an M10 Locknut (21); do not fully tighten
the Bolts yet.
Repeat this step on the other side of the
weight rack.
22
22
19
8
23
23
23
20
20
20
21
5
3
3
B
6
