WeiderPro Pro 4000 - Seat and Backrest Assembly

15
31. Attach the Backrest (16) to the Upright (3) with
two M6 x 80mm Button Screws (70) and two
M6 Washers (82).
30. Attach the Low Cable (53) to the M10 x 52mm
Button Bolt (66) used in step 28 with an M10
Nylon Locknut (56).
32.
Attach the Seat (15) to the Seat Frame (6) with
two M6 x 80mm Button Screws (70) and two
M6 W
ashers (82).
30
31
32
16
70
70
82
82
3
15
82
70
6
Seat Assembly
29. Route the Low Cable (53) over a 90mm Pulley
(48). Attach the Pulley, a Cable Trap (51), and
t
wo Half Guards (43) to the Adjustable “U”-
bracket (45) with an M10 x 52mm Button Bolt
(
66) and an M10 Nylon Locknut (56).
29
56
43
43
48
45
66
53
56
53
66
51
