Operating instructions, Piercing press, Weidmann Type MV5 Version: May 2019 Page 8
Production stoppage
This operation may be undertaken by: third parties; mechanics
The following procedure must be used in the event of production stoppages:
 Rotary table (slot width) in the wrong position: turn to the correct position as necessary
 Foreign body between table plate and workpiece: remove foreign body as necessary
Malfunction of the piercing press
This operation may be undertaken by: third parties; mechanics
The following procedure must be used in the event of a malfunction of the piercing press:
 The press spindle lowers of its own accord: apply the spindle brake
 Unstable table: check whether the table is located on the pins
 Unstable table: tighten the 2 table handle bars
Taking out of service
This operation may be undertaken by: third parties; mechanics
The following procedure must be used to take the equipment out of service:
 Raise the rotary table and lift it out of the centring hole on the table
 Move the press spindle completely to its lowest position and apply the spindle brake
Risk of crushing
Do not place your hands within the area of risk caused by the spindle
Risk of being pulled in
Do not touch the gear rim
 Check whether the 2 table clamping levers have been tightened; if not, tighten them now
 Check whether the table is located on the bearing pins; if not, move them onto the pins now
 Loosen the Hilti HSA stud anchorson the floor
 Use a crane to place the piercing press on a pallet (see operating method for Transport, Page 3)
