Specialized Concentrated Focused
「40」Machining Operations
2. Park Site
1. Park M ode
Fig. 4-9 Park MCS site interface
Select Park Mode, and then press [OK] to enter the interface as shown below.
To park site
[OK] Select
To W CS Origin
Not move
Fig. 4-10 Park mode selection
Press the Up or Down key to select the desired item, and then press the [OK] key to accomplish the
selection and return to the previous page. If To park site is selected and confirmed, input or select the
park site under 2. Park Site.
After selecting Select Site, press the [OK] key, and then press [OK] again to set current position as the
park position. The system will then back to the main page automatically. At this time, you can press the
Start key to start machining directly.
Current position cannot be set under “Selecting Site”; you need to set the current position of the spindle in
advance.
4.7.3. Spindle Stop
Press the Menu key→ 4. Oper Param→ 10. SpindleStop, and then press the [OK] key to enter the
setting interface of Spindle Stop, in which press the Up or Down key to select the corresponding
parameter for modification. See Fig. 4-11 for the three modes of spindle stop.
2. SOff at Stop
1. SOff at Pause
Yes
3. SOff at End
Fig. 4-11 Spindle stop setting interface
