Table 13 EG/PEG replacement parts
Part Number 550-110-639/0512
33
EG
•
PEG
•
EGH Gas-firEd boilErs — sEriEs 4 — boilEr manual
Replacement parts — EG/PEG
Item Description Boiler
Models
Part Number
A Left hand end section with heater opening (Pattern No.
1814)
— 311-800-014
Left end section without heater opening(Pattern No.
1813)
— 311-800-007
B
Right hand end section without heater opening
(Pattern No. 18118)
— 311-800-029
C
Intermediate section (Pattern No. 1815) — 311-800-010
D
Draft hood EG-30 450-021-255
EG-35 450-021-256
EG-40 450-021-257
EG-45 450-021-258
EG-50 450-021-259
EG-55 450-021-260
EG-65 450-021-261
EG-75 450-021-262
E
Collector hood EG-30, 35 450-014-733
EG-40, 45 450-014-734
EG-50, 55 450-014-735
EG-65 450-014-736
EG-75 450-014-737
F
Burner, steel tube, regular stainless — 512-200-000
F
1
Burner, steel tube, with pilot bracket
“PI” system (ALL)
“SPN” system (EG-75)
“SPL” system (ALL)
— 512-200-001
Burner, steel tube, with slot and pilot bracket
“SPN” system
(EG-30 & -65 Only)
— 512-200-002
G
Manifold EG-30 591-125-533
EG-35 591-125-538
EG-40 591-125-534
EG-45 591-125-539
EG-50 591-125-535
EG-55 591-125-540
EG-65 591-125-541
EG-75 591-125-542
Main burner orifice, natural gas, 2.45mm (note 1)
(not shown)
— 560-528-987
Main burner orifice, propane gas, 1.55mm (note 1)
(not shown)
— 560-528-988
Section assembly, complete without heater opening
(not shown)
EG-30, 35 321-811-095
Section assembly, complete with heater opening
(not shown)
EG-35 321-811-100
Section assembly, complete with heater opening
(not shown)
EG-40, 45 321-811-110
Section assembly, complete without heater opening
(not shown)
EG-40, 45 321-811-115
Section assembly, complete with heater opening
(not shown)
EG-50, 55 321-811-120
Section assembly, complete without heater opening
(not shown)
EG-50, 55 321-811-125
Section assembly, complete with heater opening
(not shown)
EG-65 321-811-130
Section assembly, complete without heater opening
(not shown)
EG-65 321-811-135
Section assembly, complete with heater opening
(not shown)
EG-75 321-811-140
Section assembly, complete without heater opening
(not shown)
EG-75 321-811-145
Retort cement (1 quart) (not shown) — 591-602-913
Flue brush (not shown) — 591-706-214
Item Description Boiler
Models
Part Number
H
Front base panel EG-30, 35 451-800-000
EG-40, 45 450-800-001
EG-50, 55 451-800-002
EG-65 451-800-003
EG-75 451-800-004
H
1
Base insulation kit (includes front and rear base panel
insulation, water glass, and boiler cement)
— 510-811-660
H
2
Base front access panel with flame rollout switch
bracket
EG-30, 35 451-800-040
EG-40, 45 451-800-041
EG-50 451-800-039
EG-55 451-800-042
EG-65 451-800-043
EG-75 451-800-044
H
3
Back burner support EG-30 451-800-085
EG-35 451-800-086
EG-40 451-800-087
EG-45 451-800-088
EG-50 451-800-089
EG-55 451-800-090
EG-65 451-800-092
EG-75 451-800-094
I
Back base panel EG-30, 35 451-800-010
EG-40, 45 451-800-011
EG-50, 55 451-800-012
EG-65 451-800-013
EG-75 451-800-014
I
2
Base back channel EG-30, 35 451-800-020
EG-40, 45 451-800-021
EG-50, 55 451-800-022
EG-65 451-800-023
EG-75 451-800-024
J
Base side rail (2 required) — 451-800-070
K
Spill switch — 510-300-013
L
Cover plate for heater opening (rectangular) — 389-900-103
L
2
Gasket for cover plate (rectangular) — 590-317-579
L
3
Cover plate for heater opening (round) — 389-900-101
L
4
Gasket for cover plate (round) — 590-317-495
Section replacement kit (includes 3” and 6” elastomer
seal, 2 pieces of rope, tube of silicone; order 1 per joint
between sections)
(not shown)
— 381-800-667
3” diameter bottom elastomer seal
(1 per joint)
(not shown)
— 592-800-010
6” diameter top elastomer seal (1 per joint) (not shown) — 592-800-007
Sealer for sections (2 pieces of rope, tube of silicone
per joint)
(not shown)
— 591-641-865
¹⁄₂” Tie rod without nut (2 per boiler) (not shown) EG-30, 35 560-234-470
¹⁄₂” Tie rod without nut (2 per boiler) (not shown) EG-40, 45 560-234-475
¹⁄₂” Tie rod without nut (2 per boiler) (not shown) EG-50, 55 560-234-480
¹⁄₂” Tie rod without nut (2 per boiler) (not shown) EG-65 560-234-485
¹⁄₂” Tie rod without nut (2 per boiler) (not shown) EG-75 560-234-490
¹⁄₂” Nut (2 per tie rod) (not shown) — 561-928-221
¹⁄₂” Lock washer (1 per tie rod) (not shown) — 562-248-668
Note 1: Order sufficient quantities to replace all orifices within a base.
