Technical and performance data 25
Tidal volumes and respiratory
frequencies (cycles per minute)
The follwing frequencies and tidal volumes are ob-
tained during ventilation with COMBIBAG:
Inspiratory Oxygen concentration
The oxygen concentration achievable during ventila-
tion depends on the oxygen flow set, the minute vol-
ume and the respiratory frequency. The follwing
oxygen concentrations are achieved, depending
upon the type of oxygen supply (direct supply or ox-
ygen supply with reservoir):
Frequency: adults: 12/min
children, hand: 20/min
children, 3 fingers: 25/min
Cycles per min. Tidal volume in ml
Child grip
2 fingers
3 fingers
4 fingers
hand
> 60
100 - 150
150 - 200
200 - 300
300 - 500
Adult grip
1 hand
2 hands
> 25 500 - 950
950 - 1200
Flow Adults Children
l/min
without with
reservoir
%%
ganze Hand
without with
reservoir
%%
3 Finger
without with
reservoir
%%
2 283531373546
4 36 48 36 52 43 70
6 395940654783
9 43 73 46 79 53 95
12 46 83 49 90 58 100
15 48 87 53 96 59 100
