3.2 Function
Connection lead
The BiRec MVLED/MLED remote-receiver can be fitted to any connection that has its own
connector. The receiver has connection leads for the awning, valance (BiRec MVLED only), light
and mains supply. The remote-receiver is supplied pre-fitted to the awning and with all the cables
ready-connected.
Connector pin assignment
The following connector pin assignment is used (see Fig. 1 for details):
• 2-pole AMP male connector, 230 V
• 2 flat plugs, 2.8x0.8, male/female: light LED
• 4-pole AMP female connector: motors for awning and Valance Plus
Valance Plus (BiRec MVLED only)
The Valance Plus has a total height of up to 210 cm. You will need to adapt the actual extension
height required to the conditions on site. You can do this by programming the end position (see
separate instructions).
The cable for the valance motor is laid with protection in a corrugated pipe, through the Arm
profiles.
Scope of delivery
In the case of individual deliveries, the BiRec MVLED/MLED remote-receiver is delivered as
follows:
• Remote-receiver with connection leads for the awning, Valance Plus (BiRec MVLED only),
light and mains supply
• Operating instructions
