18
Extraction forces for wall installation
I/K/N 2000 extraction forces
Wall installation on C20/25 concrete with up to 200 mm of facing,
extraction force in N per upper fixing for wall bracket
Width
in cm
Projection in cm
150 200 250 300 350 400
250
932 1979 1955
466 990 978
233 495 489
270 400 568
300
1076 1595 2257 2971
538 798 1129 1486
269 399 564 743
312 462 654 862
350
1220 1811 2560 3372 4399
610 906 1280 1686 2200
305 453 640 843 1100
354 526 742 978 1276
400
1364 2028 2862 3773 4912 6908
682 1014 1431 1887 2456 3454
341 507 716 943 1228 1727
396 588 830 1094 1424 2004
450
1508 2244 3164 4174 5425 7653*
754 1122 1582 2087 2713 3827
377 561 791 1044 1356 1913
438 650 918 1210 1574 2220
500
1652 2461 3466 4575 6736 8398*
826 1231 1733 2288 3368 4199
413 615 867 1144 1684 2100
480 714 1006 1326 1954 2436
550
1796 2677 3768 5533 7331* 9143*
898 1339 1884 2767 3666 4572
449 669 942 1383 1833 2286
520 776 1092 1634 2126 2868
600
1940 2894 4070 6095 7927* 9888*
970 1447 2035 3048 3964 4944
485 724 1018 1524 1982 2472
562 840 1180 1768 2298 3084
650
2085 3110 4925 6558 8522* 10633*
1043 1555 2463 3249 4261 5317
521 778 1231 1640 2131 2658
604 902 1428 1902 2472 3300
700
1486 2217 3514 4680 6079 7585
743 1109 1757 2340 3040 3793
372 554 879 1170 1520 1896
430 642 1018 1358 1762 2200
The extraction force is the force with which the
weight of the awning and the wind load pull on
each upper fixing. The tables indicate this force
in N per upper fixing. It varies depending on the
awning size and the wall bracket/mounting
plate used.
Selecting the wall bracket and anchoring
system:
1. Consult relevant table for extraction force
per fixing for selected awning size.
2. Select a wall bracket/mounting plate for
which there is a fastener which can resist the
indicated extraction force. Remember to take
into account the spacing, the area which will
be damaged if the fixing breaks out, the type
of fixing used and the assembly base.
See separate bracket overview for other bases.
1 standard wall bracket (85 mm) plus
1 standard wall bracket (85 mm) as a
central bracket from 401 cm,
1 standard wall bracket (85 mm)
per awning arm,
fasteners: 4 in all
1 standard wall bracket (85 mm) plus
1 standard wall bracket (85 mm) as a
central bracket from 401 cm,
2 standard wall brackets (85 mm) per
awning arm,
fasteners: 8 in all
or
1 wall bracket (260 mm) plus
1 standard wall bracket (85 mm)
as a central bracket from 401 cm,
1 wall bracket (260 mm) per awning
arm,
fasteners: 8 in all
1 wall bracket (260 mm) plus
1 standard wall bracket (85 mm)
as a central bracket from 401 cm,
2 wall brackets (260 mm) per awning
arm,
fasteners: 16 in all
Mounting plate (280 x 240 mm) incl.
1 standard wall bracket (85 mm),
standard wall bracket (85 mm) incl.
base plate,
fasteners: 8 in all
* 2 brackets required per awning arm
