weinor I 2000 - Installation Options

14
Installation options
Installation on walls, ceilings or rafters –
suitable for various building conditions
Wall installation
Wall bracket, 85 mm Wall bracket, 260 mm
14
ø 9
M8
180.25
22.25
74.75
6
145.5
85
34.5
16
14
51 17
9
Side view with 85 mm wall bracket
153
200
82
12.5
9055
180
211
Its dimensions mean that the K 2000
can be mounted in a wide range of
ways: not only on a wall but also on
a ceiling or a rafter.
The I 2000, open at the rear, is
designed for wall installation, while
the N 2000 is intended as a special
product for niches. The brackets are
made of extruded, powder-coated
aluminium.
