LINKED SPM
®
FSR MEASUREMENTS
USE THIS PROCEDURE TO DETERMINE APPROXIMATE AMOUNT
OF OVERLAP WHEN LINKING SPM
®
FSR COMPONENTS
TOGETHER.
Note that linking the SPM
®
FSR Spines together results in a slight
reduction in the combined length.
SPM
®
FSR Ribs
Note that linking the SPM
®
FSR Ribs together results in a slight
reduction in the combined length.
NOTE: ALL LENGTHS ARE APPROXIMATE & SHOULD BE USED
FOR REFERENCE ONLY
10 ft. 10 ft.
19 ft.
One foot overlap
(two Spines)
10 ft. Spines shown,
though all spines would
have similar reduction
4 ft. 4 ft.
7’ 6”
6” overlap (two ribs)
