54 mm
2 1/8 in
38 mm
1 1/2 in
actual
size
T
2 / 4
What is the diameter of the hole in the door?
Remove battery cover and battery pack from interior assembly. Install interior assembly onto mounting plate.
Locate screws for step 3C and keep them within reach.
Install exterior touchscreen and mounting plate.
A
A B
B
C
Diameter is 54 mm
(2 1/8 in)
Diameter is 38 mm
(1 1/2 in)
or
“D” is required for installation.
Install “D” on “F.”
“D” is not needed for
installation. Discard “D.”
Cable goes
underneath latch.
Support exterior
assembly during
mounting plate
installation.
Route cable through
centre hole, then push
cable into bottom hole.
Insert key and
test latch. If latch
does not extend or
retract smoothly,
adjust screws (T).
Remove key when
inished and make
sure the latch bolt
is fully extended.
Keep parallel to
edge of door.
Tighten
screws evenly.
a
a
c
c
b
b
d
d
Make sure turnpiece is in
the vertical position.
Make sure
turnpiece shaft is
rotated as shown.
Do not install batteries
until step 5.
Alarm will sound if
battery is installed
before cable is
connected.
K
J
K
This step will teach your lock the orientation of your door and is crucial to lock operation.
Install 4 AA batteries in battery pack. Make sure the door is open, and
insert the battery pack.
After a few seconds, the latch bolt will retract and extend on
its own to learn the orientation of the door. This is called the
door handing process, and it is crucial to lock operation.
If the touchscreen indicates a failure, attempt this procedure again.
If the door handing process is still unsuccessful after a second
attempt, perform the “Manual Door Handing” procedure on page 4.
A B C
D
Ensure correct polarity.
For best results, use
new, non-rechargeable
alkaline batteries only.
Once the door handing process
is complete, the touchscreen
will indicate success or failure:
Success:
lashing checkmark
symbol and single
column of digits
Failure:
lashing
“X” pattern
Ensure tight cable
connection.
Lay excess cable lat inside the
bottom of the interior housing.
align
L
U
(2x)
a
c
b
d
U
actual
size
bottom
hole
D
D
F
F
G
T
T (2x)
T
E
M
L
L
L
K
3
Install the exterior touchscreen
4
Install the interior assembly
5
Install the batteries and perform the door handing process
