Weiser SMARTCODE5 - SmartCode Installation & Programming Manual; Getting Started; Quick Reference

1 2
3 4
5 6
7 8
9 0
UP
Copyright © 2009 Black & Decker Corporation
25605-02 Weiser SmartCode Manual
Program
Button
Mounting
Holes
Turnpiece
Lock
Button
Cylinder
Settings
Switch
Panel
Keypad
LED
Cylinder
Getting Started
1
Quick Reference
●Referto“QuickReference”areaandillustrationstoidentifycomponents.
●Preparedoor,peradditionalinstructions(included)beforeinstallingunit.
●IMPORTANT:Readinstructionscompletelybeforebeginninginstallation.
Use the checklist below to assure completion of important steps.
□ATTACHCONNECTOR..........................................
□RUN“BOLTDIRECTION”DETERMINATION.......
□PROGRAMCODE(S).............................................
□VERIFYOPERATION.............................................
Section 5
Section 8
Section 9 a, b, c
Section 9 d
Installation&ProgrammingManual
Interior
Assembly
Interior
Cover
Exterior
Assembly
Adapter
Bolt
Mounting
Plate
Mounting
Bolts
Interior
Assembly
Exterior
Assembly
