Installation and operating instruction
Fieldbus module EM3/2
7 Technical documentation
83296302 1/2018-01 La
15-32
Byte Bit Information Description S
from Extended-Transfer
EB6 0…7 Setpoint degree of modulation LowByte 16-Bit setpoint degree of modulation X
EB7 0…7 HighByte 16-Bit setpoint degree of modulation X
EB8 0…7 Setpoint position of air actuator LowByte 16-Bit setpoint position of air actuator X
EB9 0…7 Highbyte 16-Bit setpoint position of air actuator X
EB10 0…7 Setpoint position of gas actu-
ator
Lowbyte 16-Bit setpoint position of gas actuator X
EB11 0…7 Highbyte 16-Bit setpoint position of gas actuator X
EB12 0…7 Fan setpoint speed in % Lowbyte 16-Bit fan setpoint speed X
EB13 0…7 Highbyte 16-Bit fan setpoint speed X
EB14 0…7 Actual fan speed in rpm Lowbyte 16-Bit actual fan speed 0
EB15 0…7 Highbyte 16-Bit actual fan speed 0
EB16 0…7 Start-up counter oil and gas
(fixed)
Byte 0 (Lowbyte) 32-Bit start-up counter X
EB17 0…7 Byte 1 X
EB18 0…7 Byte 2 X
EB19 0…7 Byte 3 (Highbyte) 32-Bit start-up counter X
EB20 0…7 Operating hours counter Gas in
seconds (fixed)
Byte 0 (Lowbyte) 32-Bit operating hours counter X
EB21 0…7 Byte 1 X
EB22 0…7 Byte 2 X
EB23 0…7 Byte 3 (Highbyte) 32-Bit operating hours counter X
EB24 0…7 Operating hours counter oil
stage 1 in seconds (fixed)
Byte 0 (Lowbyte) 32-Bit operating hours counter X
EB25 0…7 Byte 1 X
EB26 0…7 Byte 2 X
EB27 0…7 Byte 3 (Highbyte) 32-Bit operating hours counter X
EB28 0…7 Operating hours counter oil
stage 2 in seconds (fixed)
Byte 0 (Lowbyte) 32-Bit operating hours counter X
EB29 0…7 Byte 1 X
EB30 0…7 Byte 2 X
EB31 0…7 Byte 3 (Highbyte) 32-Bit operating hours counter X
EB32 0…7 not used – 0
EB33 0…7 not used – 0
from Special-Extended-Transfer
EB34 0…7 Actual degree of modulation Lowbyte 16-Bit actual degree of modulation X
EB35 0…7 Highbyte 16-Bit actual degree of modulation X
EB36 0…7 Actual position of air actuator Lowbyte 16-Bit actual position of air actuator 0
EB37 0…7 Highbyte 16-Bit actual position of air actuator 0
EB38 0…7 Actual position of Gas actuator Lowbyte 16-Bit actual position of gas actuator 0
EB39 0…7 Highbyte 16-Bit actual position of gas actuator 0
EB40 0…7 Start-up counter oil and gas
(can be reset)
Byte 0 (Lowbyte) 32-Bit start-up counter X
EB41 0…7 Byte 1 X
EB42 0…7 Byte 2 X
EB43 0…7 Byte 3 (Highbyte) 32-Bit start-up counter X
EB44 0…7 Operating hours counter oil and
gas in seconds (can be reset)
Byte 0 (Lowbyte) 32-Bit operating hours counter X
EB45 0…7 Byte 1 X
EB46 0…7 Byte 2 X
EB47 0…7 Byte 3 (Highbyte) 32-Bit operating hours counter X
