Installation and operating instruction
Fieldbus module EM3/2
4 Installation
83296302 1/2018-01 La
8-32
4 Installation
4.1 Electrical connection
DANGER
Risk of electric shock
Working on the device when voltage is applied can lead to electric shock.
Isolate the device from the power supply prior to starting any work.
Safeguard against accidental restart.
The electrical connection must only be carried out by qualified electricians. Ob-
serve local regulations.
Profibus
Do not exceed maximum cable length.
Data rate [kBit/s] 9.6 19.2 45.45 93.75 187.5 500 1500 3000 6000 12000
Max. length [m] 1200 1200 1200 1200 1000 400 200 100 100 100
Modbus
Do not exceed maximum cable length of 1000metres.
Wiring diagram
The termination (line termination) can be activated via the DIP switches. If the ter-
mination is activated via the DIP switches, no external termination resistor must be
connected.
Connect Bus connections as shown on wiring diagram.
W-FM 25
A
VCC (5V)
B
GND
1 2 3 4
EM3/2
