Weishaupt EM3/2 - Page 19

Installation and operating instruction
Fieldbus module EM3/2
7 Technical documentation
83296302 1/2018-01 La
19-32
Index Bit Information Description
111 0 … 15 Degree of modulation default in
%
– or –
Degree of modulation default in
0.01%
Lowbyte depending on config-
uration of Bits 10 and 11 in Re-
gister 110
If register110 Bit 10 = 0 and Bit 11 = 1:
Gas operation:
Degree of modulation default in %
Oil operation:
Degree of modulation default ≤ 25 % = stage 1
Degree of modulation default ≥ 75 % = stage 2
If register110 Bit 10 = 1 and Bit 11 = 1:
Gas operation:
Degree of modulation default in 0.01 % (10000 equal
to 100 %)
Oil operation:
Degree of modulation default ≤ 25 % (2500) = stage
1
Degree of modulation default ≥ 75 % (7500) = stage
2
112 0 … 15 not used –
