Installation and operating instruction
Fieldbus module EM3/2
7 Technical documentation
83296302 1/2018-01 La
22-32
Index Bit Information Description S
24 0…7 Operating hours counter oil
stage 1 in seconds (fixed)
Byte 0 (Lowbyte) 32-Bit operating hours counter X
8…15 not used – 0
25 0…7 Operating hours counter oil
stage 1 in seconds (fixed)
Byte 1 X
8…15 not used – 0
26 0…7 Operating hours counter oil
stage 1 in seconds (fixed)
Byte 2 X
8…15 not used – 0
27 0…7 Operating hours counter oil
stage 1 in seconds (fixed)
Byte 3 (Highbyte) 32-Bit operating hours counter X
8…15 not used – 0
28 0…7 Operating hours counter oil
stage 2 in seconds (fixed)
Byte 0 (Lowbyte) 32-Bit operating hours counter X
8…15 not used – 0
29 0…7 Operating hours counter oil
stage 2 in seconds (fixed)
Byte 1 X
8…15 not used – 0
30 0…7 Operating hours counter oil
stage 2 in seconds (fixed)
Byte 2 X
8…15 not used – 0
31 0…7 Operating hours counter oil
stage 2 in seconds (fixed)
Byte 3 (Highbyte) 32-Bit operating hours counter X
8…15 not used – 0
32 0…15 not used – 0
33 0…15 not used – 0
34 0…7 Actual degree of modulation Lowbyte 16-Bit actual degree of modulation X
8…15 not used – 0
35 0…7 Actual degree of modulation Highbyte 16-Bit actual degree of modulation X
8…15 not used – 0
36 0…7 Actual position of air actuator Lowbyte 16-Bit actual position of air actuator 0
8…15 not used – 0
37 0…7 Actual position of air actuator Highbyte 16-Bit actual position of air actuator 0
8…15 not used – 0
38 0…7 Actual position of Gas actuator Lowbyte 16-Bit actual position of gas actuator 0
8…15 not used – 0
39 0…7 Actual position of Gas actuator Highbyte 16-Bit actual position of gas actuator 0
8…15 not used – 0
