25 WAS.handling Electro Documentation
3.6 Motor connection
The delivered Lines are completely pre-configured. To prevent interchanging the lines of the two axis, the lines
are signed as follows:
Vertikal axis: red left drive control (with Slot-PLC “AC140“)
Horizontal axis: blue right drive control (with module “AC110“)
The wires of the motor lines are signed with specified indications. The motor lines have to be fixed with the
supplied cable brackets to ensure, the shield is also well connected.
Observe the allocation of shield
