WEISS HP140 - Page 31

WAS.handling Electro Documentation 28
Digital In- and Outputs I/O-Module:
Inputs:
Clamp on
I/O-extension
(CX408)
Function Description
X1-1
GND (0V) 24V-Supply of Inputs
X1-2
+24V /
DC_OK
24V-Supply of Inputs
X1-3
E 1.1 Configurable via Windows-Program
X1-4
E 1.2 Configurable via Windows-Program
X1-5
E 1.3 Configurable via Windows-Program
X1-6
E 1.4 Configurable via Windows-Program
X1-7
E 1.5 Configurable via Windows-Program
X1-8
E 1.6 Configurable via Windows-Program
X1-9
E 1.7 Configurable via Windows-Program
X1-10
E 1.8 Configurable via Windows-Program
X1-11
E 1.9 Configurable via Windows-Program
X1-12
E 1.10 Configurable via Windows-Program
X1-13
E 1.11 Configurable via Windows-Program
X1-14
E 1.12 Configurable via Windows-Program
X1-15
E 1.13 Configurable via Windows-Program
X1-16
E 1.14 Configurable via Windows-Program
X1-17
E 1.15 Configurable via Windows-Program
X1-18
E 1.16 Configurable via Windows-Program
Outputs:
Clamp on
I/O-extension
(CX408)
Function Description
X2-1
GND (0V) 24V-Supply of Outputs
X2-2
+24V 24V-Supply of Outputs
X2-3
A 1.1 Configurable via Windows-Program
X2-4
A 1.2 Configurable via Windows-Program
X2-5
A 1.3 Configurable via Windows-Program
X2-6
A 1.4 Configurable via Windows-Program
X2-7
A 1.5 Configurable via Windows-Program
X2-8
A 1.6 Configurable via Windows-Program
X2-9
A 1.7 Configurable via Windows-Program
X2-10
A 1.8 Configurable via Windows-Program
X2-11
A 1.9 Configurable via Windows-Program
X2-12
A 1.10 Configurable via Windows-Program
X2-13
A 1.11 Configurable via Windows-Program
X2-14
A 1.12 Configurable via Windows-Program
X2-15
A 1.13 Configurable via Windows-Program
X2-16
A 1.14 Configurable via Windows-Program
X2-17
A 1.15 Configurable via Windows-Program
X2-18
A 1.16 Configurable via Windows-Program
