3.2 Terminal connection
Terminal Function Level Comment Multipoint plug, 32-pin
+ +24V Supply voltage 3/4/A/B
- GND (OV) Supply voltage 1/2/A/B
1 Rotation direction LOW CW
HIGH CCW
Input 24V 26A
2 Enable
(RESET/Stop)
LOW: - Disable
- Reset Alarm
HIGH: ENABLE
Input 24V 19A
3 Start “edge“
rising edge
Input 24V 18A
4 Automatic Output 24V/100mA 16B
5 additional stop Log. “1“ activ Input 24V 18B
6 Alarm: Position overrun Output 24V/100mA 10B
7 Alarm: Drive time timeout
Motor overload
Output 24V/100mA 10A
8 Sum of alarms Output 24V/100mA 9A/B
9 Start permitted Output 24V/100mA 8B
10 Table in position Output 24V/100mA
Output 24V/100mA
8A
C Motor contactor “Forward“ Output 24V/2A 5A/B
D Brake Output 24V/2A 6A/B
E Motor contactor “Backward“ Output 24V/2A 14A/B
F Limit switch Log. “1“ activ Input 24V 15B
G Release brake Log. “1“ activ Input 24V 15A
H Start “level“ Log. “1“ activ Input 24V 17B
T Temperature sensor Log. “0“ activ Input 24V 17A
