1. Introduction
104781 - MRF-2 | MRH-2 - V2.4 - 22.07.2020 Page 9
1.8 Dimensions
MRF-2
1
2
3
4
°C
MRH-2
R
5
1
2
3
4
°C
Panel cutout
87,5 x 66,5 mm
Pin size welding studs M3
96 x 53 mm
