Welbach ALPHA 225 - Unpacking, Preparation & Assembly

EN EN
64
SPECIFICATIONS
Model ENTRIX 315
Rated input voltage (V) 3~400
Power frequency (HZ) 50
Rated input current (A) 11
Rated input power (KVA) 7
Welding current (A) TIG DC 20-315
Welding current (A)TIG AC 30-300
Welding current (A) MMA 30-315
No-load voltage (V) 64
Pulse frequency (Hz) 0.2~500(DC) 0.2~20(AC)
Pulse and empty ration (%) 1~99
AC frequency (Hz) 20 - 150
AC clean width (%) -40 ~ +40
AC clean scope (%) -
Current up/down slope time (S) 1 - 15
Gas pre-ow time (S) 1 - 99,9
Gas post-ow time (S) 0 ~ 99.9
Rated duty cycle TIG DC
35%@315A
80%@241A
100%@186A
Rated duty cycle TIG AC
35%@300A
80%@229A
100%@177A
Rated duty cycle MMA
35%@315
80%@203A
100%@158A
Efciency (under rated condition) ≥0.85
IF YOU INTEND TO USE THIS WELDING APPARATUS WITH MORE THAN 150
AMPERES, IT MUST BE CONNECTED TO A WATER COOLING SYSTEM.
Duty Cycle
Duty Cycle is the equipment specications which denes the number of minutes
within a 10 minute period that a piece of equipment can safely operate.
UNPACKING
When unpacking, checks to make sure the following parts are included.
• Inverter welding machine with
• TIG torch with Power Cord
• Ground Cable with Clamp
• Welding hold with cord
• Back-up Accessories for torch
• Service card; Quality card
If any parts are missing or broken, please call our service team at the number on the
cover of this manual.
Please keep these two cards (Especially the serial number on them) well for your
after-sales service.
PREPARING YOUR WORK AREA
1. You must have a sturdy work table that is open below the area you are cutting.
Molten slag will be blown through the work metal, and must be able to fall away
freely
2. Your work table must allow the work metal to be rmly clamped to prevent it
accidentally falling or moving.
3. The oor and surrounding area of your work site must not be ammable. A clean
cement oor is recommended. The cutting process will eject molten metal slag
onto the oor, and it will scatter for 8-10 feet or more in any direction. Have an
adequate re extinguisher available if needed.
65
Power Factors 0.7 ~ 0.9
Insulation grade IP21S
