Problem Symptom Root cause Solution
Batteries are inserted
incorrectly.
Insert the batteries correctly
AC adapter is inserted
incorrectly.
Insert the AC adapter tightly
Low batteries
The display indicates the
“BAT-LO” message, pauses for
3 seconds. The battery icon
shows empty (does not flash).
Batteries are low. Replace with new batteries
Error messages
E 01 shows The cuff is not secure. Readjust the cuff, relax for a
moment, and then measure
again
E 03 shows There is too much pressure in
the cuff.
Refasten the cuff and then
measure again
E 10 or E 11 shows The monitor detected motion
while measuring.
Readjust the cuff, relax for a
moment, and then measure
again
Hardware error
EE and E 19 shows Malfunctioning hardware Measure again. If the problem
persists, contact the retailer or
Welch Allyn customer service
at www.welchallynhome.com
for further assistance.
Physiological alarm indications
Symptom
Root cause Solution
Out of range. Either SYS >260mmHg or DIA
>220mmHg. The symbol may appear in
either the SYS or DIA area of the screen.
Press and hold the Power button to
reestablish Bluetooth connectivity.
Measure again. If the problem persists,
contact your physician.
Alarm priority = Low
Out of range. Either SYS <50mmHg or DIA
<25mmHg. The symbol may appear in either
the SYS or DIA area of the screen.
Press and hold the Power button to
reestablish Bluetooth connectivity.
Measure again. If the problem persists,
contact your physician.
Alarm priority = Low
20 Maintenance and troubleshooting Welch Allyn Remote Monitoring Blood Pressure Device RPM-BP100SBP
