Weldclass CutForce CF-45P - Know Your Machine; Machine Front; Machine Rear

.
6 © Weldclass 2019 | E.&O.E. | Edition 1.0 2019.05
3.1 Machine Front
1. Carry Handle
2. Control panel
3. Plasma Torch Central Connector (Negative (-))
4. Earth Lead Connection Socket (Positive (+))
3.2 Machine Rear
5. 240V AC Mains Power Input Lead
6. Mains Power Switch
7. Air Regulator Adjustment Knob
8. Air Regulator Gauge
9. Compressed Air Inlet Connection
10. Air Regulator
11. Air Filter Bowl
12. Air Filter Moisture Drain Tube
3
4
2
1
Figure 1
6
8
9
Figure 2
7
10
11
12
5
