Page 8
ASSEMBLY INSTRUCTIONS
For the ARC 170
Slide the right wheel and axle into position. At-
tach the left wheel onto the axle and insert the R
Clips to retain wheels.
For the ARC 170
Fit the front leg to the base into position and se-
cure with screws.
For both the ARC 140 and ARC 170
Slide the handle into the grooves on top of the
machine and insert screws.
For the ARC 170
Slide the handle extension through the handle
and secure with screw..
