Weldmatic W65 4RD - Electrical Schematics; W65 + W66 Wirefeeder Circuit Diagram

Weldmatic W65 + W66 4RD Wirefeeder
Model No W65, W66 13
9.1 W65 + W66 Wirefeeder Circuit Diagram
W65-0
WIRE FEEDER W65-0
A
WIRE FEED MOTOR
GAS VALVE
CONTROL LEAD
CURRENT
RELAY
GUN SWITCH
WIRE SPEED CALIBRATION
MAXIMUM SPEED ADJUSTED
BY RV7
TO 159 RPM FOR W65 TO 172 RPM FOR W66
BLACK
BLACK
RED
RED
PLUG
ELEC CONT +
ELEC CONT -
12
345
6
(FRONT VIEW)
FINE VOLT (0V) FINE VOLT (0~12V)
32Vac
7
Fig 4 W65 +W66 Wirefeeder Circuit Diagram
