Operators Manual
Trusted by the best
3 Specifications
Wirefeeder
Supply Voltage
32 volts AC, (from welding power source)
Rated Supply Current
5 Amps
Pre-gas Range
0 - 2 seconds
Post-gas Range
0 - 2 seconds
Start Speed
Normal or Creep (switchable)
Spool Sizes
5 kg, 15 kg
Wirespeed Range
W65: 0 - 159 RPM
W66: 0 - 172 RPM
0 - 20 Metres per min
(0 - 10 Metres per min Low Speed Range,
8 - 20 Metres per min High Speed Range)
Wire Size Range
0.6mm - 1.6mm diameter
1 Power on Indicator
This indicator is illuminated when wirefeeder
is connected to a power source and the
power source is switched on.
2 Arc start
This control can be set to modify arc starting
conditions. For many applications the control
can be set at the mid point.
Rotating the knob towards ‘FAST’ will
provide faster wire acceleration at arc start
giving quicker starts, suitable for applications
such as rapid tack welding.
Rotating the knob towards ‘SOFT’ will
slow wire acceleration, providing a softer
start suitable for larger diameter and
aluminium wires.
3 Wire Speed Control
This control sets the speed of the wire drive
motor equivalent to 0 - 20 metres per minute
of welding electrode wire. Rotate the control
clockwise to increase the feed speed.
This control is used in conjunction with the
Wire Speed Range Select Switch. Switch to
low for slower (0-10 metres/min wirespeed
control and switch to high for higher
(8-20 metres/min) wire speeds.
4 Wire Speed Range Indicator Light
This indicator is illuminated when speed
range is set to High speed range (8-20
metres/min).
5 Wire Speed Range Select Switch
Press to change from Low wire speed range
to High wire speed range.
4 Controls
