Weldmax Pulse Technik Series - MMA and DC TIG Welding Settings

Cod.006.0001.1440
03/06/2013 v2.2
ENGLISH
300T
16/28
11 WELDING SETTINGS
11.1 ELECTRODE WELDING (MMA)
S5
This button serves to select the following welding mode:
MMA
MMA PARAMETERS SETTING (1ST LEVEL) 11.1.1
S3
Press this button to scroll the list of settings to edit.
The selected parameter and its value are shown on the following displays: D2
E1
Using the encoder, edit the value of the selected setting.
The value is saved automatically.
Press any key (except S3) to save the setting and quit the menu.
Tab. 3 - Parameters of the 1st level menu in MMA mode
PARAMETER
MIN
DEFAULT
MAX
WELDING CURRENT
10 A
80 A
300 A
MAX WELDING CURRENT
5 A
80 A
300 A
HOT-START
0 %
50 %
100 %
*1
ARC-FORCE
0 %
30 %
100 %
*1
*1: This parameter is set as a percentage referred to the value of the following parameter: WELDING CURRENT
MMA PARAMETERS SETTING (2ND LEVEL) 11.1.2
S3
Hold down the button for 3 seconds to gain access to the 2nd level menu.
L.2
The message appears on the following displays:
D1
L.2= LEVEL.2= 2ND LEVEL MENU
The selected parameter and its value are shown on the following displays: D2
S3
Press this button to scroll the list of settings to edit.
E1
Using the encoder, edit the value of the selected setting.
The value is saved automatically.
Press any key (except S3) to save the setting and quit the menu.
Tab. 4 - Parameters of the 2nd level menu in MMA mode
PARAMETER
MIN
DEFAULT
MAX
VRD
OFF
OFF
ON
*3
LONG ARC VOLTAGE
37
SYN
65
*4
REMOTE CONTROL
OFF
OFF
ON
*2
*2: The activation is suitable for the following welding modes:
 MMA
 DC TIG
 AC TIG
Compatible remote control types:
 manual remote controller.
*3: The activation is suitable for the following welding modes:
 MMA
*4: SYN: This code indicates that parameters control is synergic. The optimal value of this parameter is set automatically by the microprocessor
on the basis of the preset welding current value. This value can be displayed but it is not user-adjustable.
MMA SPECIAL FUNCTIONS 11.1.3
S1
Press this button to scroll the list of settings to edit.
The selected parameter and its value are shown on the following displays: D2
E1
Using the encoder, edit the value of the selected setting.
The value is saved automatically.
Press any key (except S1) to save the setting and quit the menu.
