Depending on the chosen configuration, Aquasoul Pro can
support up to 4 speakers, 1 subwoofer, an auxiliary input, a
USB connection with 1A charging capability, FM radio receiv-
er and Bluetooth streaming.
The in.p4 waterproof enclosure, which provides protection to
your iPod or smart phone, is available as an option.
With a compatible keypad, you will have full control over the
Aquasoul Pro features from inside of your hot tub.
USB
AUX input
in.p4
Bluetooth
Subwoofer
Left
Front
Right
Rear
Left
Right
AC input
Communication link
Remove the cover screws from the front of the apparatuswith
a Phillips screw driver.
Remove cover and put aside the foam gaskets located in the
wire channel.
TO PREVENT ELECTRIC SHOCK HAZARD, DO NOT CONNECT TO MAIN POWER SUPPLY WHILE
THE COVER IS REMOVED.
CONNECTIONS
PREPAR ATION
OPTIONAL ACCESSORIES AQUASOUL PRO
