Wen 20512BT User Manual

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 20512-001 Bolt 1
2 20512-002 Copper Spacer A 1
3 20512-003 Torsion Spring 1
4 20512-004 Revolving Shaft 1
5 20512-005 Copper Spacer B 1
6 20512-006 End Link 1
7 20512-007 Press Plate 1
8 20512-008 Bolt 1
9 20512-009 Self-locking nut 1
10 20512-010 Copper Spacer C 1
11 20512-011 Pendulum Bar 1
12 20512-012 Washer 1
13 20512-013 Bolt 1
14 20512-014 Seal 1
15 20512-015 Drive Cylinder 1
16 20512-016 O-ring 1
17 20512-017 Seal 1
18 20512-018 Drive Piston Seal 1
19 20512-019 Drive Piston 1
20 20512-020 Pin 1
21 20512-021 Magnet 1
22 20512-022 Drive Link 1
23 20512-023 Pin 1
24 20512-024 Drive Shaft 1
25 20512-025
Temperature Sensor
Cover
1
26 20512-026 Temperature Sensor 1
27 20512-027 Drive Bumper 1
28 20512-028 Bolt 6
29 20512-029
Pressure Cylinder
Cover
1
30 20512-030 Cylinder Cover Seal 1
31 20512-031 Cylinder Inner Cover 1
32 20512-032 Seal 1
33 20512-033 Pressure Cylinder 1
34 20512-034 Seal 1
35 20512-035 Pressure Piston 1
36 20512-036
Horizontal Piston
Rod
1
37 20512-037 Bolt 1
No. Part No. Description Qty.
38 20512-038
Pressure Piston
Shaft
1
39 20512-039 Pin 1
40 20512-040 Pivoted Axle Magnet 1
41 20512-041 Pivoted Axle 1
42 20512-042 Trigger Switch 1
43 20512-043 Spring 1
44 20512-044 Trigger 1
45 20512-045 LED Switch 1
46 20512-046 Spring 1
47 20512-047 LED Trigger 1
48 20512-048 Bolt 2
49 20512-049 Bolt 4
50 20512-050
Pressure Piston
Support
1
51 20512-051 Bearing 2
52 20512-052 Connecting Rod 1
53 20512-053 Gear A 4
54 20512-054 Gear Tray A 1
55 20512-055 Gear B 7
56 20512-056 Gear Tray B 1
57 20512-057 Inner Gear A 1
58 20512-058 Inner Gear B 1
59 20512-059 Spacer 1
60 20512-060 Bolt 2
61 20512-061 Motor Cover 1
62 20512-062 Pin 2
63 20512-063 Axis Shaft 1
64 20512-064 Motor 1
65 20512-065 Left Housing 1
66 20512-066 Right Housing 1
67 20512-067 Housing Screws 10
68 20512-068 Belt Hook 1
69 20512-069 Bolt 1
70 20512-070 Nut 1
71 20512-071 Terminal Connector 1
72 20512-072 Battery 1
73 20512-073 Dryfire Safety Switch 1
74 20512-074 Spacer 2
18
