EXPLODED VIEW & PARTS LIST
NOTE: Not all parts may be available for purchase. Parts and accessories that wear down over the course of
normal use are not covered under the warranty.
NOTE: *Only included with model number 20512.
No. Part No. Description Qty.
75 20512-075 Spring 1
76 20512-076 Switch Shaft 1
77 20512-077 Spring 1
78 20512-078
Depth Adjustment
Wheel
1
79 20512-079 Screw 1
80 20512-080 LED Lighting 1
81 20512-081 Magazine Sensor 1
82 20512-082
Magazine Sensor
Housing
1
83 20512-083 Controller 1
84 20512-084
Mode Selector
Switch
1
85 20512-085 Mode Selector 1
86 20512-086 Cap 2
87 20512-087 Bolt 2
88 20512-088 Bolt 2
89 20512-089 Bolt 2
90 20512-090 Bolt 1
91 20512-091 Spring 1
92 20512-092 Steel ball 1
93 20512-093 Drive Housing 1
94 20512-094
Safety Switch
Linkage
1
95 20512-095 Spring 1
96 20512-096 Impact Nub 2
97 20512-097
Pressure Adjustment
Plate
1
No. Part No. Description Qty.
98 20512-098 Bolt 2
99 20512-099 Drive Head 1
100 20512-100 Bolt 2
101 20512-101 Bolt 2
102 20512-102 Drive Plate 1
103 20512-103 Magazine 1
104 20512-104 Iron Wire 1
105 20512-105 Support 1
106 20512-106 Bolt 3
107 20512-107 Lock Lever 1
108 20512-108 Pin 1
109 20512-109 Rubber 1
110 20512-110 Spring 1
111 20512-111 Bolt 1
112 20512-112 Baffle 1
113 20512-113 Nail Feeder 1
114 20512-114
Window Plastic
Piece
2
115 20512-115 Spring 2
116 20512-116 Magazine Cover 1
117 20512-117 Magazine End Cover 1
118 20512-118 Bolt 1
119 20512-119 Charger 1
120 20512-120 Hex Wrench 1
19
