Wen 3424T User Manual

21
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 3424-001 Rear Spindle Wheel 1
2 3424-002 Set Screw 2
3 3424-003 Ball Bearing, 6004ZZ 1
4 3424-004 Retaining Ring 1
5 3424-005 Headstock 1
6 3424-006 Back Cover 1
7 3424-007
Back Cover
Locking Knob
1
8 3424-008 M6×16 Screw 1
9 3424-009 Retaining Ring 1
10 3424-010 Ball Bearing, 6005ZZ 1
11 3424-011 Key 1
12 3424-012 Spindle Shaft 1
13 3424-013 Face Plate 1
14 3424-014 Spur Center 1
15 3424-015 Live Center 1
16 3424-016 Quill 1
17 3424-017 Screw Stem 1
18 3424-018 Retaining Ring 1
19 3424-019 Tailstock 1
20 3424-020 Set Screw 1
21 3424-021 Quill Locking Handle 1
22 3424-022 Tailstock Locking Lever 1
24 3424-024 Handle 1
25 3424-025 Handle Screw 1
26 3424-026 Handwheel 1
27 3424-027 Set Screw 2
28 3424-028 Drawbar, Tailstock 1
29 3424-029 Retaining Ring 1
30 3424-030 Drawbar, Tool Rest 1
31 3424-031 Tool Rest Locking Handle 1
32 3424-032-1 Tool Rest Base 1
33 3424-033 Retaining Ring 1
34 3424-034-1 Tool Rest 1
35 3424-035 Set Screw 1
36 3424-036
Tool Rest
Locking Lever
1
37 3424-037 Drive Belt 1
38 3424-038 Spindle Pulley 1
39 3424-039 Mounting Screw, Headstock 4
40 3424-040 Lock Washer 4
41 3424-041 Set Screw 1
42 3424-042 Bushing 1
No. Part No. Description Qty.
43 3424-043 Side Cover Locking Knob 1
44 3424-044 Left Cover 1
45 3424-045 M6×16 Screw 2
46 3424-046 Base 1
47 3424-047 Foot M8-1.25 4
48 3424-048 Set Screw 2
49 3424-049 Motor Pulley 1
50 3424-050 Motor Mounting Screw 4
51 3424-051 Lock Washer 4
52 3424-052 Motor Support Plate 1
53 3424-053 Flat Washer 1
54 3424-054 Motor Plate Lock Handle 1
55 3424-055 Flat Washer 1
56 3424-056 Lock Washer 1
57 3424-057 Hex Head Bolt 1
58 3424-058 Cord Clamp 3
59 3424-059 M5×10 Pan Head Screw 3
60 3424-060-1 Motor 1
61 3424-061 Clamp 1
62 3424-062 M10 Hex Nut 1
63 3424-063 Switch Plate 1
64 3424-064 Switch 1
65 3424-065
ST3.5×16 Self-Tapping
Screw
2
66 3424-066 Switch Box 1
67 3424-067 Bushing 2
68 3424-068 End Stop Plate 1
69 3424-069 M8×12 Pan Head Screw 2
70 3424-070 Strain Relief 1
71 3424-071 Power Cord 1
72 3424-072 M5×10 Pan Head Screw 2
73 3424-073 Lock Washer M5 2
74 3424-074 Flat Washer M5 2
75 3424-075 Grounding Terminal 2
76 3424-076 Serrated Washer 2
77 3424-077 3mm Hex Wrench 1
78 3424-078 5mm Hex Wrench 1
79 3424-079 Wrench 1
80 3424-080 Knockout Rod 1
81 3424-081 Tool Holder 1
82 3424-082 M5×12 Pan Head Screw 2
83 3424-083 Sealing Plate 1
84 3424-084 Rubber Ring 1
