Wen 4208 Operator's Manual

3
CONTENTS
Technical data…..……………………………………………………….. 3
General safety rules…….……………………………………………….. 4
Specific safety rules for drill press……………………………………… 6
Electrical information…………………………………………………... 7
Assembly and adjustments……………………………………………… 9
Operation………………………………………………………………... 16
Maintenance…………………………………………………………….. 19
Exploded view…………………………………………………………… 20
Parts list………………………………………………………………… 21
Warranty………………………………………………………………… 22
TECHNICAL DATA
 8" Drill Press Model# 4208
 Motor: 120 V, 60 Hz, 2.3 A, 1/3HP
 Horsepower: 1/3 HP (single phase)
 Drilling capacity: 2"
 Drill Depth / Spindle Travel: 2"
 Chuck capacity: 1/2"
 Table size: 6-1/2" x 6-1/2" (16 x 16 cm)
 Pulley speeds: 5 (620, 1100, 1720, 2340, 3100 RPM)
 Overall height: 22.8" (58 cm)
 Weight: 35 lb
Warning! We strongly recommend that this item not be modified and/or used for any application
other than that for which it was designed. If you have any questions relative to its application, do not
use the equipment until you have consulted us and we have advised you.
Contact Great Lakes Technologies, LLC at (800)232-1195M-F 8am-5pm CST

Wen 4208 Specifications

General

Brand	Wen
Model	4208
Category	Power Tool
Language	English
