Wen 4208 Operator's Manual

21
PARTS LIST
Part #
Stock #
Description
Part #
Stock #
Description
1
4208-001
BELT
33
4208-033
SCREW ST4.2X9.5
2
4208-002
SET SCREW M8X10
34
4208-034
ON/OFF SWITCH
3
4208-003
SPINDLE PULLEY
35
4208-035
RETAINING RING 11
4
4208-004
MOTOR PULLEY
36
4208-036
BEARING
5
4208-005
WASHER
37
4208-037
WASHER
6
4208-006
SCREW M6X8
38
4208-038
QUILL
7
4208-007
PULLEY COVER
39
4208-039
BEARING
8
4208-008
RETAINING RING 22
40
4208-040
SPINDLE SHAFT
9
4208-009
PULLEY INSERT
41
4208-041
SCREW M5X20
10
4208-010
SCREW M8X25
42
4208-042
SET RING
11
4208-011
WASHER
43
4208-043
CHUCK
12
4208-012
MOTOR
44
4208-044
NUT M6
13
4208-013
RUBBER STOPPER
45
4208-045
NUT M5
14
4208-014
MOTOR STOP
46
4208-046
STOP ROD
15
4208-015
SPRING
47
4208-047
NUT M10
16
4208-016
SHAFT
48
4208-048
POINTER
17
4208-017
HEAD
49
4208-049
SPRING CAP
18
4208-018
BEARING
50
4208-050
COIL SPRING
19
4208-019
RETAINING RING 17
51
4208-051
SPRING SEAT
20
4208-020
SCREW M8X8
52
4208-052
NUT M8
21
4208-021
SET SCREW M8X8
53
4208-053
COLUMN
22
4208-022
LOCK KNOB
54
4208-054
TABLE SUPPORT
23
4208-023
KNOB
55
4208-055
LOCK HANDLE
24
4208-024
FEED HANDLE
56
4208-056
TABLE
25
4208-025
PINION SHAFT
57
4208-057
SCREW M12X25
26
4208-026
NUT M8
58
4208-058
SCREW M8X20
27
4208-027
SCREW
59
4208-059
SUPPORT COLUMN
28
4208-028
WASHER
60
4208-060
BASE
29
4208-029
SCREW M5X14
61
4208-061
WASHER
30
4208-030
SWITCH BOX
62
4208-062
POWER CORD
31
4208-031
SCREW M5X14
63
4208-063
CHUCK KEY
32
4208-032
SWITCH BOX COVER
64
4208-064
SAFETY LOCK KEY
