Wen 4214

ASSEMBLY & ADJUSTMENTS
EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY
A - SPINDLE PULLEY ASSEMBLY (PART 4214B-AA)
2 4214B-002 Cam 1
3 4214B-003 Set Screw, M8x12 2
4 4214B-004 Bearing, 61907 1
5 4214B-005 Spindle Movable Pulley 1
7 4214B-007 Spindle Fixed Pulley 1
124 4214B-124 Elastic Ring, Type A, Ø55 1
125 4214B-125 Circlip for Shaft, Ø35 1
B - SPINDLE SHAFT ASSEMBLY (PART 4214B-AB)
8 4214B-008 Key, Type A, 4x4x64 1
9 4214B-009 Spindle Sleeve 1
10 4214B-010 Bearing, 6203RZ 2
11 4214B-011 Retainer 1
12 4214B-012
Circlip for Shaft, Ø17 1
C - SPINDLE ASSEMBLY (PART 4214B-AC)
55 4214B-055 Bearing, 6201RZ 1
56 4214B-056 Rubber Washer 1
57 4214B-057 Quill 1
62 4214B-062 Bearing, 6204RZ 1
63 4214B-063 Spindle, MT2 1
72 4214B-1109 Hex Nut, M14 1
D - TABLE ASSEMBLY (PART 4214B-AD)
40 4214B-079 Phillips-Head Screw, M6x8 1
41 4214B-041 Flat Washer, Ø8 4
42 4214B-042 Work Table 1
44 4214B-044 Guide Rod 2
45 4214B-045 Roller Screw 2
46 4214B-046 Roller Support 1
47 4214B-047 Phillips-Head Screw, M6x12 2
48 4214B-048 Roller 1
E - COLUMN ASSEMBLY (PART 4214B-AE)
76 4214B-076 Set Screw, M8x8 3
104 4214B-104 Column 1
108 4214B-108 Column Base 1
F - TABLE SUPPORT ASSEMBLY (PART 4214B-AF)
96 4214B-096 Phillips-Head Screw, M4x8 2
97 4214B-097 Bevel Indicator 1
100 4214B-100 Table Support 1
101 4214B-101 Worm Gear 1
105 4214B-105 Inner Gear 1
106 4214B-106 Inner Gear Shaft 1
27
NO. PART NO. DESCRIPTION QTY
G - CRANK ASSEMBLY (PART 4214B-AG)
83 4214B-129 Handle 1
99 4214B-1099 Screw M6x10 3
102 4214B-102 Crank Handle 1
H - LAMP ASSEMBLY ( PART 4214B-AH)
92 4214B-1092 Phillips-Head Screw, M4x12 1
93 4214B-093 Lamp Socket Bracket 1
94 4214B-094 Lamp Socket 1
95 4214B-095 LED Lamp 1
K - MOTOR PULLEY ASSEMBLY (PART 4214B-AK)
99 4214B-1099
Screw M6x10 3
111 4214B-111 Motor Fixed Pulley 1
112 4214B-112 Motor Movable Pulley 1
L - VARIABLE SPEED HANDLE ASSEMBLY (PART 4214B-AL)
17 4214B-017 Handle Knob 4
18 4214B-018 Variable Speed Handle 1
M - SWITCHBOX ASSEMBLY (PART 4214B-AM)
14 4214B-014 Screw, ST2.9x6.5 4
29 4214B-029-01 Digital Display PCB 1
30 4214B-030 Switch Box 1
31 4214B-031 Phillips-Head Screw, M5X12 3
32 4214B-032 Main Switch 1
33 4214B-033 Lamp/Laser Switch 2
36 4214B-077 Phillips-Head Screw, M5X10 1
N - SCALE COLLAR ASSEMBLY (PART 4214B-AN)
39 4214B-061 Hex Nut, M8 1
52 4214B-052 Adjustment Nut 4
53 4214B-053 Special Washer 1
54 4214B-054 Scale 1
58 4214B-058 Nut M6 1
59 4214B-059 Scale Collar 1
60 4214B-060 Screw M6x16 1
P - SPEED SENSOR ASSEMBLY (PART 4214B-AP)
13 4214B-013 Screw, M4x20 2
14 4214B-014 Screw, ST2.9x6.5 4
15 4214B-015 Speed Sensor 1
16 4214B-016 Speed Sensor Base 1
Q - RACK COLLAR ASSEMBLY (PART 4214B-AQ)
98 4214B-098 Rack Collar 1
99 4214B-1099 Screw M6x10 3
R - SPINDLE HANDLE ASSEMBLY (PART 4214B-AR)
17 4214B-017 Handle Knob 4
122 4214B-122 Handle 3
NOTE: Parts may only be available in their respective subassemblies.
Not all parts may be available for purchase.
