Wen 4214

ASSEMBLY & ADJUSTMENTS
EXPLODED VIEW & PARTS LIST
28
NO. PART NO. DESCRIPTION QTY
1 4214B-001 Circlip for Shaft, Ø24 1
6 4214B-006 Cogged V-belt, 10x900 1
19 4214B-019 Lock Nut, M10 1
20 4214B-020 Flat Washer, Ø10 1
21 4214B-021 Handle Seat 1
22 4214B-022 Speed Adjustment Base 1
23 4214B-023 Gear Shaft 1
24 4214B-024 Key, Type A, 3x3x25 1
25 4214B-025 Hex Nut, M12 2
26 4214B-026 Coil Spring Assembly 1
27 4214B-027 Spring Baffle 1
28 4214B-028 Bushing 1
34 4214B-1001 Shaft Cover 1
35 4214B-079
Phillips-Head Screw, M6x8 1
37 4214B-136 Knob 2
38 4214B-1086 Inner Hex Bolt, M8x6 1
43 4214B-066 Screw, M5x12 1
49 4214B-049 Column Clamp 1
50 4214B-050 Table Arm 1
51 4214B-051 Hex Bolt, M12x35 1
61 4214B-061 Hex Nut, M8 5
64 4214B-064 Chuck Arbor, MT2-JT3 1
65 4214B-065 Chuck, JT3 1
66 4214B-072 Screw, M5x16 1
67 4214B-067 Cord Clamping Plate 2
68 4214B-068 Rubber Bushing 2
69 4214B-069 Cord Bushing 1
70 4214B-070 Cord Clamping Hook 1
72 4214B-1109 Hex Nut, M14 1
73 4214B-073 Belt Housing Assembly 1
74 4214B-074 Damping Pad 4
75 4214B-075 Spring Pin, 6x15 2
77 4214B-077 Phillips-Head Screw, M5x10 5
78 4214B-078 Wrench Clip 1
NO. PART NO. DESCRIPTION QTY
79 4214B-079 Screw M6x8 2
80 4214B-080 Pin 1
81 4214B-081
Phillips-Head Screw, M5x8,
with Spring & Flat Washers
2
82 4214B-1128 Spring Washer, M12 1
84 4214B-084 Star Washer Ø5 2
85 4214B-085 Quill Set Screw 1
86 4214B-086 Head 1
87 4214B-087 Laser 2
88 4214B-088 Rack Compression Spring 1
89 4214B-089 Rack Shaft 1
90 4214B-1085 Rack Bushing 1
91 4214B-091 Hex Bolt M8*12 3
103 4214B-103 Rack 1
107 4214B-107 Hex Bolt, M10x30 4
109 4214B-109 Base 1
110 4214B-110 Circlip for Shaft, Ø14 1
113 4214B-113
Motor Compression Spring 1
114 4214B-114 Spring Base 1
115 4214B-115 Spring Washer 1
116 4214B-116 Motor Assembly 1
117 4214B-117 Key, Type A, 4x4x80 1
118 4214B-118 Hex Screw, M8x16 4
119 4214B-119 Power Cord 1
120 4214B-120 Spring Washer, Ø8 3
121 4214B-121 Motor Plate 1
123 4214B-123 Handle Hub 1
126 4214B-131 Sealing Rubber Strip 4
127 4214B-132 Hex Wrench, M3 1
128 4214B-133 Hex Wrench, M4 1
129 4214B-134 Chuck Key 1
130 4214B-135 Wedge Block 1
131 4214B-1096 Wrench 1
NP 4214B-116-1 Capacitor 1
132 4214B-116CC Capacitor Cover 1
136 4214B-136 Table Support Knob 2
