KNOW YOUR BENCH GRINDER
TOOL PURPOSE
Sharpen bits, drill bits, chisels, gouges, and other cutting tools all with your WEN Bench Grinder. Refer to the fol-
lowing diagrams to become familiarized with all the parts and controls of your bench grinder. The components will
be referred to later in the manual for assembly and operation instructions.
1. INNER WHEEL GUARD - Covers the grinding wheels
and protects against accidental contact.
2. TOOL RESTS - Used to support the workpiece.
3. 36-GRIT GRINDING WHEEL - Used to remove heavy
material from the workpiece.
4. EYESHIELD - Protective see-through shields to pre-
vent any loose debris from contacting the operator.
5. LOCKING KNOB - Lock the eyeshield in position.
6. FLEXIBLE WORK LIGHT - Provides light to the opera-
tor during grinding operations.
7. SPARK DEFLECTOR - Prevents hot sparks and debris
from contacting the operator.
8. WHEEL COVER - Covers the grinding wheels and pro-
vides quick access for routine maintenance.
9. 60-GRIT GRINDING WHEEL - Used to remove light
material from the workpiece.
10. ON/OFF SWITCH - Used to turn ON and turn OFF the
bench grinder.
11. MOTOR HOUSING - Contains the electrical motor.
1
2
3
4
5
6
7
8
9
10
11
10
