Wen 4276 User Manual

No. Part No. Description QTY.
26 4276-026 Switch 1
27 4276-027 Switch Plate 1
28 4276-028 Fastener Assembly 2
29 4276-029 Bottom Plate 1
30 4276-030 Fastener Assembly 2
31 4276-031 Rubber Foot 4
32 4276-032 Capacitor 1
33 4276-033 Flat Washer 2
34 4276-034 Hex Nut 1
35 4276-035 Right Guard Cover 1
36 4276-036 Grinding Wheel 1
37 4276-037 Right Guard 1
38 4276-038 Right Tool Rest 1
39 4276-039 Fastener Assembly 2
40 4276-040 Bearing 2
41 4276-041 Cord Clip 1
42 4276-042 Rotor 1
43 4276-043 Right Eyeshield 1
44 4276-044
Right Eyeshield
Bracket
1
45 4276-045 Power Cord 1
46 4276-046 Base 1
47 4276-047 Lamp 1
48 4276-048 Eyeshield Knob 1
49 4276-049 Locking Knob 1
No. Part No. Description QTY.
1 4276-001 Bolt 2
2 4276-002 Spring Washer 2
3 4276-003 Flat Washer 2
4 4276-004 Left Eyeshield Bracket 1
5 4276-005 Left Eyeshield 1
6 4276-006 Tool Rest Lock Knob 2
7 4276-007 Left Tool Rest 1
8 4276-008 Nut 6
9 4276-009 Left Guard 1
10 4276-010 Carriage Bolt 2
11 4276-011 Fastener Assembly 2
12 4276-012 Spark Deflector 2
13 4276-013 Fastener Assembly 4
14 4276-014 Flange 4
15 4276-015 Grinding Wheel 1
16 4276-016 Hex Nut 1
17 4276-017 Left Guard Cover 1
18 4276-018 Screw 6
19 4276-019 Hex Nut 2
20 4276-020 End Cap 2
21 4276-021 Washer 1
22 4276-022 Stator 1
23 4276-023 Cord Brushing 1
24 4276-024 Washer 1
25 4276-025 Fastener Assembly 1
EXPLODED VIEW & PARTS LIST
16
