Fig. 15
A - Screw
B - Wheel guard cover
C - Wheel nut
D - Outer flange
E - Grinding wheel
F - Flange nut
G - Inner flange
H - Spindle shaft
A
B
C
D
E
F
G
H
Wheel Cover
Grinding Wheel
Hex Nut Outer Flange
Inner Flange Arbor
